THECHNICAL SHEET FOR CMAX FO/23B (TC5023)
To be supplied as per client’s specific requirements Tower crane configuration
| Name | Quantity | Specification |
| Basic mast section | One | 1.6*1.6*7.5M |
| Climbing Cage (Including cylinder, pump station ) | One | |
| L46A1 Mast section | Twelve | 1.6*1.6*3M |
| Up & low slewing groupware | One | |
| Lifting jib | One | 50M |
| Cat head | One | |
| Counter jib (Including tension bar) | One | |
| Trolley | One | |
| Hook | One | |
| Cabin (Including AC) | One | |
| Electric control system | One | |
| Hoisting mechanism | One | 55RCS25（Power: 41KW; Steel rope 500M） |
| Trolley mechanism | One | 95JXL |
| Slewing mechanism | One | RCV95 |
| Solar energy emergency light | Three pieces | |
| Embedded frame | One set | |
| Counter-weight steel bar structure | One set | |
| 1.6M fixing angle | One set |
Free parts list
1.one set of installation tools (including the tools to tight different bolts)
2.two bags of calcium base grease
3.two pieces of grease gun
4.one set of mast section connection bolts
5.six pieces of contactor
6.two control panel contact points
7.two pieces of air brake
8.one piece of rectifier
9.one barrel of paint
10. gear
11.one set of normal lifting tools
