WOLFF 8038 Clear US
Technical information
| BGL classification | C.0.10.0560 |
| Norms | EN 14439 |
| Max. load capacity | 20.0 t |
| Max. jib radius | 85.0 m |
| Rope falls | 2 |
Power requirements
| Hoisting gear: | ||
|---|---|---|
| Type | 20110 FU | |
| Power | kW | 110 |
| Current | A | 204 |
| Crane: | ||
| Operating current | A | 185 |
| Peak current | A | 303 |
| Supply line: | ||
| Cross Section A | mm² | 70 | 95 |
| Max. fuse | A | 160 | 160 |
| Max. length S2 + S3 | m | 171 | 232 |
| Connected power | kVA | 128 |
| min. required generator power | kVA | 320 |
